Spare parts support for S6800(CS660) and H6800(CH660)
Laboratory
Our laboratory is equipped with advanced experimental equipment and technology, and we adopts the world's leading testing and management technology. It is a leading testing center for castings and related products in China. We deeply know every customer's expectations and requirements for their products. Therefore, we always regard quality assurance as the most critical part of production.
WJ supports parts list as following, if any missing, please contract with me by free,
| PART NO. | DESCRIPTION | MODEL | WEIGHT(KG) |
| 442.8723 | GEAR & PINION | CH660 S6800 H6800 CS660 | |
| 442.8732 | MAIN SHAFT STEP | CH660/CS660/S6800/H6800 | |
| 442.8735 | BOTTOM SHELL | CH660/CS660/S6800/H6800 | |
| 442.8747 | INNER SEAL RING | CH660/CS660/S6800/H6800 | |
| 442.8753 | SPIDER CAP | CH660/CS660/S6800/H6800 | |
| 442.8754 | SPIDER BUSHING | CH660/CS660/S6800/H6800 | |
| 442.8755 | SEAL RING | CH660/CS660/S6800/H6800 | |
| 442.8759 | LINER NARROW ARM | CH660/CS660/S6800/H6800 | |
| 442.8762 | LOCATING BAR | CH660/CS660/S6800/H6800 | |
| 442.8763 | MANTLE HEAD | CH660/CS660/S6800/H6800 | |
| 442.8764 | PINION SHAFT HOUSING | CH660/CS660/S6800/H6800 | |
| 442.8765 | PLATE | CH660/CS660/S6800/H6800 | |
| 442.8766 | PLATE | CH660/CS660/S6800/H6800 | |
| 442.8767 | MAIN SHAFT | CH660/CS660/S6800/H6800 | |
| 442.8771 | SPACER | CH/CS660 H/S6800/6000 | |
| 442.8772 | PINION SHAFT | CH/CS660 H/S6800/6000 | |
| 442.8791 | INNER INNER HEAD NUT | CH660/CS660/S6800/H6800 | |
| 442.8792 | MAIN SHAFT SLEEVE | CH660/CS660/S6800/H6800 | |
| 442.8793 | SUPPORT RING | CH660/CS660/S6800/H6800 | |
| 442.8801 | RETAINER RING | CH660/CS660/S6800/H6800 | |
| 442.8804 | RETAINER | CH660/CS660/S6800/H6800 | |
| 442.8805 | SCRAPER | CH660/CS660/S6800/H6800 | |
| 442.8825 | ECC. BUSHING | CH660/CS660/S6800/H6800 | |
| 442.8826 | ECC. BUSHING | CH660/CS660/S6800/H6800 | |
| 442.9037 | TOP SHELL EC2 | CH660/CS660/S6800/H6800 | |
| 452.3274 | MAIN SHAFT | CH660 S6800 H6800 CS660 | |
| 452.3822 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 452.4125 | BOTTOM SHELL | CH660 S6800 H6800 CS660 | |
| 452.4309 | MAIN SHAFT | CH660 S6800 H6800 CS660 | |
| 840.0069 | BOLT | CH660 S6800 H6800 CS660 | |
| 840.0071 | BOLT | CH660 S6800 H6800 CS660 | |
| 853.0119 | DOWEL PIN | CH660 S6800 H6800 CS660 | |
| 855.0026 | RETAINING RING | CH660 S6800 H6800 CS660 | |
| 873.0128 | SEAL RING | CH660 S6800 H6800 CS660 | |
| 190.4590.91 | ELECTRIC CABLE SET | CH660/CS660/S6800/H6800 | |
| 190.4590-91 | ELECTRIC CABLE SET | CH/CS660 | |
| 190.4591.00 | CONNECTION BOX | CH660/CS660/S6800/H6800 | |
| 190.4591-00 | CONNECTION BOX | CH/CS660 | |
| 191.2376.00 | TEMPERATURE SENSOR KIT, TRPF | CH660/CS660/S6800/H6800 | |
| 191.3213.00 | CONNECTION BOX CBT | CH660/CS660/S6800/H6800 | |
| 194.0402.92 | CABINET, ELECTRICAL | CH660/CS660/S6800/H6800 | |
| 194.0402-92 | CABINET, ELECTRICAL | CH/CS660 | |
| 194.0409.003 | CABLE | CH660/CS660/S6800/H6800 | |
| 194.0409-003 | CABLE | CH/CS660 | |
| 194.0575.00 | CABINET, ELECTRICAL | CH660/CS660/S6800/H6800 | |
| 194.0575-00 | CABINET, ELECTRICAL | CH/CS660 | |
| 422.9356 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.5904-01 | FIXING PLATE H6000& H8000 | UH640/CH660/H6800 | |
| 442.6427-01 | BURNING RING S&H6000 | UH640/CH660/H6800 | |
| 442.7252-01 | SHIM 1X80X20 1142-32 H4000 | UH640/CH660/H6800 | |
| 442.7252-02 | SHIM 3X80X20 1312-00 H4000 | UH640/CH660/H6800 | |
| 442.7252-03 | SHIM 5X80X20 1312-00 H4000 | UH640/CH660/H6800 | |
| 442.7252-04 | SHIM 10X80X20 1312-00 H6000 | UH640/CH660/H6800 | |
| 442.8722.01 | MPS CYLINDER HOUSING | CH660/CS660/S6800/H6800 | |
| 442.8722-01 | HYDROSET CYLINDER S&H6000 | UH640/CH660/H6800 | |
| 442.8723.00 | GEAR SET CPL H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8723-00 | GEAR & PINION SET H6000(SOLD AS SET) | UH640/CH660/H6800 | |
| 442.8724.01 | MPS CYL BUSHING H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8724-01 | HYDROSET CYL BUSH H6000 | UH640/CH660/H6800 | |
| 442.8725.01 | MPS CLAMP PLATE PACKING H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8726.01 | CYLINDER COVER H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8726-01 | HYDROSET CYL COVER H6000 | UH640/CH660/H6800 | |
| 442.8729.001 | HUB H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8729-001 | HUB | CH/CS660 | |
| 442.8730 | PISTON WEARING PLATE | CH660 S6800 H6800 CS660 | |
| 442.8730.01 | PISTON WEARING PLATE | CH660/CS660/S6800/H6800 | |
| 442.8730-01 | PISTON WRG PLATE S&H6000 | UH640/CH660/H6800 | |
| 442.8731.01 | STEP WASHER | CH660/CS660/S6800/H6800 | |
| 442.8731-01 | STEP WASHER S&H6000 | UH640/CH660/H6800 | |
| 442.8732.01 | MAIN SHAFT STEP | CH660/CS660/S6800/H6800 | |
| 442.8732-01 | MAINSHAFT STEP S&H6000 | UH640/CH660/H6800 | |
| 442.8733.01 | ECCENTRIC /H6000/CH660 | CH660/CS660/S6800/H6800 | |
| 442.8733-01 | ECCENTRIC H6000 | UH640/CH660/H6800 | |
| 442.8735.00 | BOTTOM SHELL H/S6000 3-ARMS | CH660/CS660/S6800/H6800 | |
| 442.8735-00 | BOTTOM SHELL ASM S&H6000 | UH640/CH660/H6800 | |
| 442.8739 | CHEVRON PACKING | CH660/CS660/S6800/H6800 | |
| 442.8739.00 | CHEVRON PACKING | CH660/CS660/S6800/H6800 | |
| 442.8739-00 | CHEVRON PACKING S&H6000 | UH640/CH660/H6800 | |
| 442.8741.01/452.4151.001 | DUST COLLAR H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8741-01 | DUST COLLAR S&H6000 | UH640/CH660/H6800 | |
| 442.8742.01 | BOTTOMSHELL BUSHING H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8742-01 | BOTTOM SHELL BUSH S&H6000 | UH640/CH660/H6800 | |
| 442.8743 | RING | CH660/CS660/S6800/H6800 | |
| 442.8743.00 | RING H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8743-00 | RING (TWO PIECE) S&H6000 | UH640/CH660/H6800 | |
| 442.8744.01 | RING H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8747.01 | SEAL RING INNER H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8747-01 | INNER SEAL RING S&H6000 | UH640/CH660/H6800 | |
| 442.8749-01 | HYD CYL COVER GASKT H6000 HYD CYL CO | UH640/CH660/H6800 | |
| 442.8753.01 | SPIDER CAP TPE /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8753-01 | SPIDER CAP H6000 | UH640/CH660/H6800 | |
| 442.8754.01 | SPIDER BUSHING STD | CH660/CS660/S6800/H6800 | |
| 442.8754.MNBR/BG00248051 | SPIDER BUSHING MNBR | CH660/CS660/S6800/H6800 | |
| 442.8754-01 | SPIDER BUSHING S&H6000 | CS660/S6800 | |
| 442.8755.01 | SPIDER SEAL RING | CH660/CS660/S6800/H6800 | |
| 442.8755-01 | OIL SEAL RING S&H6000 | UH640/CH660/H6800 | |
| 442.8758.00 | PISTON ASM H6800/CH660/CS660 | CH660/CS660/S6800/H6800 | |
| 442.8758-00 | PISTON S&H6000 | UH640/CH660/H6800 | |
| 442.8759.00 | NARROW ARM LINER 14MNCR CH/CS660 (3-armed) | CH660/CS660/S6800/H6800 | |
| 442.8759-00 | NARROW ARM LINER S&H6000 | UH640/CH660/H6800 | |
| 442.8760 | LINER PIN SHAFT ARM | CH660/CS660/S6800/H6800 | |
| 442.8760.00 | PINIONSHAFT ARMLNR 14MNCR CH/CS660 (3-armed) | CH660/CS660/S6800/H6800 | |
| 442.8760-00 | PINIONSHAFT ARM LNR H6000 | UH640/CH660/H6800 | |
| 442.8761.01 | ECCENTRIC WEARING PLATE H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8761-01 | WEARING PLATE-ECC H6000 | UH640/CH660/H6800 | |
| 442.8762.01 | LOCATING BAR H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8762-01 | LOCATING BAR S&H6000 | UH640/CH660/H6800 | |
| 442.8763.01 | HEAD H6000 / USE ASSY N11851912 | CH660/CS660/S6800/H6800 | |
| 442.8763-01 | HEADCENTER H6000 | UH640/CH660/H6800 | |
| 442.8764.01 | PINION SHAFT HOUSING BARE H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8764-01 | PINIONSHAFT HSG S&H6000 | UH640/CH660/H6800 | |
| 442.8765.01 | BRNG COVER OUTER H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8765-01 | PINSHAFT SEAL PLT S&H6000 | UH640/CH660/H6800 | |
| 442.8766.01 | BRNG COVER INNER H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8766-01 | PINSHAFT SEAL PLT S&H6000 | UH640/CH660/H6800 | |
| 442.8767.01 | MAIN SHAFT H6000 / USE ASSY N11851912 | CH660/CS660/S6800/H6800 | |
| 442.8767-01 | MAINSHAFT H6000 | UH640/CH660/H6800 | |
| 442.8771.01 | SPACER RING H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8771-01 | SPACER-SHV&PIN ENDS& H6000 | UH640/CH660/H6800 | |
| 442.8772.01 | PINION SHAFT H/S600 | CH660/CS660/S6800/H6800 | |
| 442.8772-01 | PINIONSHAFT S&H6000 | UH640/CH660/H6800 | |
| 442.8774.01 | GASKET T=0.5 /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8774.02 | GASKET T=0.8 /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8774-01 | PINSHAFT SEALPLT GASKET H6000 | UH640/CH660/H6800 | |
| 442.8774-02 | PINSHAFT SEALPLT GASKET H6000 | UH640/CH660/H6800 | |
| 442.8775.01 | GASKET T=0.8 /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8775-01 | PINSHAFT SEALPLT GASKET H6000 | UH640/CH660/H6800 | |
| 442.8777-00 | CHECK VALVE | UH640/CH660/H6800 | |
| 442.8778.01 | PLUG OIL LEVEL /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8778-01 | OIL LEVEL PLUG S&H6000 | UH640/CH660/H6800 | |
| 442.8787.01 | WASHER | CH660/CS660/S6800/H6800 | |
| 442.8787-01 | WASHER-SHEAVE RETAINER H6000 | UH640/CH660/H6800 | |
| 442.8788.01 | SPACER | CH660/CS660/S6800/H6800 | |
| 442.8788-01 | SPACER-SHEAVE RETAINER H6000 | UH640/CH660/H6800 | |
| 442.8791.01 | HEAD NUT INNER | CH660/CS660/S6800/H6800 | |
| 442.8791-01 | INNER HEAD NUT H6000 **SEE I-NOTE* | UH640/CH660/H6800 | |
| 442.8792.01 | MAIN SHAFT SLEEVE | CH660/CS660/S6800/H6800 | |
| 442.8792-01 | MAINSHAFT SLEEVE H6000 | CS660/S6800 | |
| 442.8793.01 | CONCAVE SUPPORT RING | CH660/CS660/S6800/H6800 | |
| 442.8793-01 | CONCAVE CLAMPING RING H6000 | UH640/CH660/H6800 | |
| 442.8800 | HEAD NUT WITH BURNING | CH660/CS660/S6800/H6800 | |
| 442.8800.00 | HEAD NUT WITH RING | CH660/CS660/S6800/H6800 | |
| 442.8800-00 | HEADNUT W/BURN RING H6000 | UH640/CH660/H6800 | |
| 442.8801.01 | RET RING H/S 6000 | CH660/CS660/S6800/H6800 | |
| 442.8801-01 | RETAINER RING S&H6000 | UH640/CH660/H6800 | |
| 442.8802.01 | DUST SEAL RING | CH660/CS660/S6800/H6800 | |
| 442.8802-01 | DUST SEAL RING S&H6000 | UH640/CH660/H6800 | |
| 442.8803.01 | GASKET T=0,5 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8803.02 | GASKET T=0,8 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8803.03 | GASKET T=1.5 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8803-01 | PINSHAFT HSG GASKET S&H6000 | UH640/CH660/H6800 | |
| 442.8803-02 | PINSHAFT HSG GASKET S&H6000 | UH640/CH660/H6800 | |
| 442.8803-03 | PINSHAFT HSG GASKET S&H6000 | UH640/CH660/H6800 | |
| 442.8804.01 | RETAINER H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8804-01 | DUST SEAL RETAINER H6000 | UH640/CH660/H6800 | |
| 442.8805.01 | SCRAPER H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8805-01 | SCRAPER S&H6000 | CS660/S6800 | |
| 442.8807.01 | KEY | CH660/CS660/S6800/H6800 | |
| 442.8807-01 | ECC GEAR KEY S&H6000 | UH640/CH660/H6800 | |
| 442.8808.01 | GASKET /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8808-01 | DUST COLLAR GASKT S&H6000 (2-PIECE) | UH640/CH660/H6800 | |
| 442.8809.01 | SHIM T=0,1 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8809.02 | SHIM T=0,5 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8809.03 | SHIM T=0,7 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8809.04 | SHIM T=1,0 H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8809-01 | SHIM 0.1 THK(0.003) S&H6000 | UH640/CH660/H6800 | |
| 442.8809-02 | SHIM 0.5 THK(0.02) S&H6000 | UH640/CH660/H6800 | |
| 442.8809-03 | SHIM 0.7 THK(0.03) S&H6000 | UH640/CH660/H6800 | |
| 442.8809-04 | SHIM 1.0 THK(0.04) S&H6000 | UH640/CH660/H6800 | |
| 442.8812.01 | SPIDER ARM SHIELD 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8812-01 | SPIDER ARM SHIELD H6000 | UH640/CH660/H6800 | |
| 442.8813 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.8813.01 | CONCAVE EC 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8813.02 | CONCAVE EC 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8813.03 | CONCAVE EC 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8813-01 | CONCAVE RNG EC M1 H6800 | UH640/CH660/H6800 | |
| 442.8813-02 | CONCAVE RNG EC M2 H6800 | UH640/CH660/H6800 | |
| 442.8813-03 | CONCAVE EC | CH660 | |
| 442.8814 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.8814.01 | CONCAVE C 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8814.02 | CONCAVE C 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8814.03 | CONCAVE C 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8814-01 | CONCAVE RING C M1 H6800 | UH640/CH660/H6800 | |
| 442.8814-02 | CONCAVE RING C M2 H6800 | UH640/CH660/H6800 | |
| 442.8814-03 | CONCAVE C | CH660 H6800 | |
| 442.8815 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.8815.01 | CONCAVE MF 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8815.02 | CONCAVE MC 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8815.03 | CONCAVE MC 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8815-01 | CONCAVE RNG MC M1 H6800 | UH640/CH660/H6800 | |
| 442.8815-02 | CONCAVE RNG MC M2 H6800 | UH640/CH660/H6800 | |
| 442.8815-03 | CONCAVE MC | CH660 H6800 | |
| 442.8816 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.8816.01 | CONCAVE M 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8816.02 | CONCAVE M 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8816.03 | CONCAVE M 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8816-01 | CONCAVE RING M M1 H6800 | UH640/CH660/H6800 | |
| 442.8816-02 | CONCAVE RING M M2 H6800 | UH640/CH660/H6800 | |
| 442.8816-03 | CONCAVE M | CH660 H6800 | |
| 442.8817 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.8817.01 | CONCAVE MF 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8817.02 | CONCAVE MF 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8817.03 | CONCAVE MF 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8817-01 | CONCAVE RNG MF M1 H6800 | UH640/CH660/H6800 | |
| 442.8817-02 | CONCAVE RNG MF M2 H6800 | UH640/CH660/H6800 | |
| 442.8817-03 | CONCAVE MF | CH660 H6800 | |
| 442.8818 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.8818.01 | CONCAVE F 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8818.02 | CONCAVE F 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8818.03 | CONCAVE F 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8818-01 | CONCAVE RING F M1 H6800 | UH640/CH660/H6800 | |
| 442.8818-02 | CONCAVE RING F M2 H6800 | UH640/CH660/H6800 | |
| 442.8818-03 | CONCAVE F | CH660 H6800 | |
| 442.8819 | MANTLE | CH660/CS660/S6800/H6800 | |
| 442.8819.01 | MANTLE A 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8819.02 | MANTLE A 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8819.03 | MANTLE A 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8819-01 | MANTLE A M1 H6800 | UH640/CH660/H6800 | |
| 442.8819-02 | MANTLE A M2 H6800 | UH640/CH660/H6800 | |
| 442.8819-03 | MANTLE A | CH660 H6800 | |
| 442.8820 | MANTLE | CH660/CS660/S6800/H6800 | |
| 442.8820.01 | MANTLE B 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8820.02 | MANTLE B 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8820.03 | MANTLE B 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8820-01 | MANTLE B M1 H6800 | UH640/CH660/H6800 | |
| 442.8820-02 | MANTLE B M2 H6800 | UH640/CH660/H6800 | |
| 442.8820-03 | MANTLE B | CH660 H6800 | |
| 442.8821 | MANTLE | CH660/CS660/S6800/H6800 | |
| 442.8821.01 | MANTLE D 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8821.02 | MANTLE D 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8821.03 | MANTLE D 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.8821-01 | MANTLE D M1 H6800 | UH640/CH660/H6800 | |
| 442.8821-02 | MANTLE D M2 H6800 | UH640/CH660/H6800 | |
| 442.8821-03 | MANTLE D | CH660 H6800 | |
| 442.8823 | TORCH RING | CH660/CS660/S6800/H6800 | |
| 442.8823.01 | FILLER RING M/MC | CH660/CS660/S6800/H6800 | |
| 442.8823-01 | FILLER RING (M & MC) H6000 | UH640/CH660/H6800 | |
| 442.8824.01 | ECCENTRIC BUSHING 18+20+24+28 /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8824-01 | ECC BUSH 18+20+24+28 H6000 | UH640/CH660/H6800 | |
| 442.8825.01 | ECCENTRIC BUSHING 28+32+36+40 /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8825-01 | ECC BUSH 28+32+36+40 H6000 | UH640/CH660/H6800 | |
| 442.8826.01 | ECCENTRIC BUSHING 40+44+48+50 /H6000 | CH660/CS660/S6800/H6800 | |
| 442.8826-01 | ECC BUSH 40+44+48+50 H6000 | UH640/CH660/H6800 | |
| 442.8847.901/BG00598827 | PINION SHAFT HOUSING ASSY H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.8847-901 | PINIONSHAFT ASSY (LESS PINION) | UH640/CH660/H6800 | |
| 442.8848.901/452.3272.901 | MAIN SHAFT ASSEMBLY H6000 | CH660/CS660/S6800/H6800 | |
| 442.8848-901 | MAINSHAFT ASM H6000 | UH640/CH660/H6800 | |
| 442.8849-901 | TOPSHELL EC2 | UH640/CH660/H6800 | |
| 442.8860.00 | FOOT ASSEMBLY | CH660/CS660/S6800/H6800 | |
| 442.8860-00 | FOOT ASSEMBLY | CH/CS660 H6800 | |
| 442.8863 | TORCH RING | CH660/CS660/S6800/H6800 | |
| 442.8863.01 | FILLER RING F/MF | CH660/CS660/S6800/H6800 | |
| 442.8863-01 | FILLER RING (F, MF) H6000 | UH640/CH660/H6800 | |
| 442.8879-00 | LIFTING TOOL/ECC SL H6000 | UH640/CH660/H6800 | |
| 442.8880-00 | LIFTING TOOL/BTM SHELL | UH640/CH660/H6800 | |
| 442.8881.01 | WASHER FOR FILLER RING CH660 | CH660/CS660/S6800/H6800 | |
| 442.8881-01 | WASHER-CONCAVE H6000 | UH640/CH660/H6800 | |
| 442.8908.02 | HOSE 31,5/0,6 L=245 | CH660/CS660/S6800/H6800 | |
| 442.8908-01 | HOSE H6000 | UH640/CH660/H6800 | |
| 442.8969.00/BG00395422 | SPIDER S6000 | CH660/CS660/S6800/H6800 | |
| 442.8969-00 | SPIDER S6000 | CS660/S6800 | |
| 442.8970 | TOP SHELL | CH660/CS660/S6800/H6800 | |
| 442.8970.01/452.5837-901 | TOP SHELL W/O SPIDER S6800/CS660 | CH660/CS660/S6800/H6800 | |
| 442.8970-01 | TOPSHELL S6000 | CS660/S6800 | |
| 442.8970-01/452.5837-901 | TOP SHELL W/O SPIDER | S6800/CS660 | |
| 442.8971.01 | MAIN SHAFT S6000 / USE ASSY N11852162 | CH660/CS660/S6800/H6800 | |
| 442.8971-01 | MAINSHAFT S6000 | CS660/S6800 | |
| 442.8973-01 | ECCENTRIC S6000 | CS660/S6800 | |
| 442.8974.01 | HEAD S6000 / USE ASSY | CH660/CS660/S6800/H6800 | |
| 442.8974-01 | HEADCENTER S6000 | CS660/S6800 | |
| 442.8975 | RIM LINER | CH660/CS660/S6800/H6800 | |
| 442.8975.01 | SPIDER RIM LINER (x12) /S6800/CS660 | CH660/CS660/S6800/H6800 | |
| 442.8975-01 | RIM LINER S6000 | CS660/S6800 | |
| 442.8976.01 | SPIDER ARM SHIELD /S6800/CS660 | CH660/CS660/S6800/H6800 | |
| 442.8976-01 | SPIDER ARM SHIELD S6800 | CS660/S6800 | |
| 442.8977.01 | SPIDER CAP /S6000 | CH660/CS660/S6800/H6800 | |
| 442.8977-01 | SPIDER CAP S6000 | CS660/S6800 | |
| 442.8979 | CONCAVE LOW | CH660/CS660/S6800/H6800 | |
| 442.8979-00 | CONCAVE LWR EC M1 S6800 | CS660/S6800 | |
| 442.8981 | CONCAVE UPR | CH660/CS660/S6800/H6800 | |
| 442.8981-00 | CONCAVE UPR EC M1 S6800 | CS660/S6800 | |
| 442.8982 | MANTLE | CH660/CS660/S6800/H6800 | |
| 442.8982-01 | MANTLE A M1 S6800 | CS660/S6800 | |
| 442.8982-02 | MANTLE A M2 S6800 | CS660/S6800 | |
| 442.8983 | MANTLE | CH660/CS660/S6800/H6800 | |
| 442.8983.01 | MANTLE B 14MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.8983.02 | MANTLE B 18MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.8983.03 | MANTLE B 21MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.8983-01 | MANTLE B M1 S6800 | CS660/S6800 | |
| 442.8983-02 | MANTLE B | CS660 S6800 | |
| 442.8983-03 | MANTLE B | CS660 S6800 | |
| 442.9033.01 | ECCENTRIC BUSHING 20+25+30+35+40 /S6800/CS660 | CH660/CS660/S6800/H6800 | |
| 442.9033-01 | ECC BSHG 20-25-30-35-40 S6000 | CS660/S6800 | |
| 442.9037.00 | TOP SHELL EC2 (OLD STYLE) | CH660/CS660/S6800/H6800 | |
| 442.9037-00 | TOP SHELL EC2 | CH660 S6800 H6800 CS660 | |
| 442.9039.00 | BOTTOM SHELL LINER KIT 3-ARMS | CH660/CS660/S6800/H6800 | |
| 442.9039-00 | BOTTOM SHELL LINER KIT | CH/CS660 | |
| 442.9040-01 | PINION ARM SIDE LINR 6000 | CS660/S6800 | |
| 442.9041-01 | NARROW ARM SIDE LNR 6000 | CS660/S6800 | |
| 442.9042-01 | ACCESS HOLE SIDE LNR 6000 | CS660/S6800 | |
| 442.9043 | WEAR PLATE | CH660/CS660/S6800/H6800 | |
| 442.9043-01 | BSHELL SIDE LINER H/S6000 | CS660/S6800 | |
| 442.9071 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.9071.00 | CONCAVE RING LOWER C 14MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.9071.90 | CONCAVE RING LOWER C 18MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.9071-00 | CONCAVE LWR C M1 S6800 | CS660/S6800 | |
| 442.9071-90 | LOWER CONCAVE RING C M2 S6800 | CS660/S6800 | |
| 442.9072 | CONCAVE UPR | CH660/CS660/S6800/H6800 | |
| 442.9072.00 | CONCAVE RING UPPER C 14MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.9072.90 | CONCAVE RING UPPER C 18MNCR CS660 | CH660/CS660/S6800/H6800 | |
| 442.9072-00 | CONCAVE UPR C M1 S6800 | CS660/S6800 | |
| 442.9072-90 | CONCAVE RING-UPR C M2 S6800 | CS660/S6800 | |
| 442.9086.01 | BRACKET (FOR S_MODEL) | CH660/CS660/S6800/H6800 | |
| 442.9086-01 | BRACKET | CH/CS660 | |
| 442.9172.01 | KEY (FOR S-MODEL) | CH660/CS660/S6800/H6800 | |
| 442.9172-01 | KEY | CH/CS660 | |
| 442.9230 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 442.9230.01 | CONCAVE CX 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.9230.02 | CONCAVE CX 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.9230.03 | CONCAVE CX 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.9230-01 | CONCAVE CX | CH660 H6800 | |
| 442.9230-02 | CONCAVE CX | CH660 H6800 | |
| 442.9230-03 | CONCAVE CX | CH660 H6800 | |
| 442.9355 | MANTLE | CH660 H6800 | |
| 442.9355-01 | MANTLE EF M1 H6800 | UH640/CH660/H6800 | |
| 442.9356 | CONCAVE | CH660 H6800 | |
| 442.9356-01 | CONCAVE RNG EF M1 H6800 | UH640/CH660/H6800 | |
| 442.9356-02 | CONCAVE RNG EF M2 H6800 | UH640/CH660/H6800 | |
| 442.9415.00 | WEAR PLATE FOR CONCAVE EF | CH660/CS660/S6800/H6800 | |
| 442.9415-00 | WEAR PLATE | UH640/CH660/H6800 | |
| 442.9610.01 | KEY R 28X16X320, H/S6000 | CH660/CS660/S6800/H6800 | |
| 442.9760 | MANTLE | CH660/CS660/S6800/H6800 | |
| 442.9760.01 | MANTLE HC 14MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.9760.02 | MANTLE HC 18MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.9760.03 | MANTLE HC 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 442.9760-01 | MANTLE HC | CH660 H6800 | |
| 442.9760-02 | MANTLE HC | CH660/H6800 | |
| 442.9760-03 | MANTLE HC | CH660/H6800 | |
| 442.9781-00 | TOP PLATE COMP MTGH&S6000 | UH640/CH660/H6800 | |
| 452.0269 | TORCH RING | CH660/CS660/S6800/H6800 | |
| 452.0269.001 | BURNING RING H51/ H6000 | CH660/CS660/S6800/H6800 | |
| 452.0269-001 | TORCH RING | CH660 H/S6800 H6000 | |
| 452.0820 | MANTLE | CH660 H6800 | |
| 452.0820-001 | MANTLE H6000 EEF M1 | UH640/CH660/H6800 | |
| 452.0820-002 | MANTLE EEF M2 H6800 | UH640/CH660/H6800 | |
| 452.0832 | CONCAVE | CH660 H6800 | |
| 452.0832-001 | CONCAVE H6000 EEF M1 | UH640/CH660/H6800 | |
| 452.0832-002 | CONCAVE EEF M2 H6800 | UH640/CH660/H6800 | |
| 452.1543.003 | MANTLE D SPECIAL 21MNCR CH660 | CH660/CS660/S6800/H6800 | |
| 452.1543-003 | MANTLE D | CH660 | |
| 452.1700-901 | MAINSHAFT ASY W/O MANTLE S6800 | CS660/S6800 | |
| 452.2382.901 | FEED HOPPER CONE CX LEFT | CH660/CS660/S6800/H6800 | |
| 452.2382.902 | FEED HOPPER CONE CX RIGHT | CH660/CS660/S6800/H6800 | |
| 452.2382-901 | FEED HOPPER CONE CX LEFT | CH660/CS660 | |
| 452.2382-902 | FEED HOPPER CONE CX RIGHT | CH660/CS660 | |
| 452.3760.901 | TOP SHELL (BARE MACHINING) WITH RAISED ARMS | CH660/CS660/S6800/H6800 | |
| 452.3760-901 | TOP SHELL WITH RAISED ARMS | CH660/CS660 | |
| 452.3765.001 | BOTTOM SHELL BARE 5-ARMS CH/CS660 | CH660/CS660/S6800/H6800 | |
| 452.3765-001 | BOTTOM SHELL | CH/CS660 | |
| 452.3841.001 | SPIDER CAP CH660 (NEW STYLE) | CH660/CS660/S6800/H6800 | |
| 452.3841-001 | SPIDER CAP | CH660 | |
| 452.4129.001 | DUST COLLAR KIT | CH660/CS660/S6800/H6800 | |
| 452.4129-001 | DUST COLLAR KIT | CH660/CS660 | |
| 452.4130.901 | HEAD ASSY | CH660/CS660/S6800/H6800 | |
| 452.4130.902 | HEAD ASSY | CH660/CS660/S6800/H6800 | |
| 452.4130-901 | HEAD ASSY | CH660 S6800 H6800 CS660 | |
| 452.4130-902 | HEAD ASSY | CH660 S6800 H6800 CS660 | |
| 452.4153.001 | PIPE, STEEL DIN 2391/C-ST 35,4, 10X1,5 | CH660/CS660/S6800/H6800 | |
| 452.4153-001 | PIPE | CH660/CS660 | |
| 452.4222.901/452.1700.901/452.1640.901 | MAIN SHAFT ASSEMBLY | CH660/CS660/S6800/H6800 | |
| 452.5222.001/BG00277273 | PINIONSHAFT ARMLNR CH660:2 (x1 for 5-armed) | CH660/CS660/S6800/H6800 | |
| 452.5222-001/BG00277273 | PINIONSHAFT ARMLNR | CH660 | |
| 452.5227.001 | NARROW ARM LINER CH660:2 (x4 for 5-armed) | CH660/CS660/S6800/H6800 | |
| 452.5227-001 | NARROW ARM LINER | CH660 | |
| 452.5543.901 | FILTER KIT | CH660/CS660/S6800/H6800 | |
| 452.5543-901 | FILTER KIT | CH660 S6800 H6800 CS660 | |
| 452.5862.901 | SPIDER CAP DOME, TOP / CS660, S6800 | CH660/CS660/S6800/H6800 | |
| 452.5862-901 | SPIDER CAP DOME | CS660/S6800 | |
| 452.5920 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 452.6027 | MANTLE | CH660 H6800 | |
| 452.7282.901 | WEAR LINER KIT, HB400 W/FASTENERS BTM-SHELL 5-ARM | CH660/CS660/S6800/H6800 | |
| 452.7282-901 | WEAR LINER KIT | CH660 | |
| 452.9040 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 452.9041 | CONCAVE | CH660/CS660/S6800/H6800 | |
| 650.0086.19 | HOSE SAE 100 R1AT R1/4 X 1100 (FOR S-MODEL) | CH660/CS660/S6800/H6800 | |
| 650.0086-19 | HOSE | CH660/CS660 | |
| 840.0072.00 | BOLT, HEXAGONAL ISO4014-M16X70-8.8-A3A | CH660/CS660/S6800/H6800 | |
| 840.0072-00 | BOLT | CH870/H7000/CS660 | |
| 840.0650.00 | SCREW M6S 20X65 8.8 ISO4017 / S6000/CS660 | CH660/CS660/S6800/H6800 | |
| 840.0650-00 | SCREW | CS660/H/S6000 | |
| 840.0669.00 | SCREW, HEXAGONAL ISO4017-M24X70-8.8-A3A | CH660/CS660/S6800/H6800 | |
| 840.0672.00 | BOLT, HEXAGONAL ISO4014-M24X100-8.8-A3A | CH660/CS660/S6800/H6800 | |
| 840.0674.00 | SCREW, HEXAGONAL ISO4017-M24X120-8.8-A3A | CH660/CS660/S6800/H6800 | |
| 840.0674-00 | SCREW | CS660/CJ613 | |
| 840.0943-00 | BOLT | CH660/H6800 | |
| 840.1063-00 | SCREW | CS660/CH870/H7000 | |
| 840.1073-00 | BOLT | CS660 | |
| 840.1075.00 | Screw M6S 30x380 | CH660/CS660/S6800/H6800 | |
| 840.1075-00 | SCREW | CH660 | |
| 840.1124.00 | BOLT, HEXAGONAL ISO4014-M42X280-10.9-UNPLTD (FOR S-MODEL) | CH660/CS660/S6800/H6800 | |
| 841.0028.00 | SCREW, CAP, HEXAGON SOCKET HEAD ISO4762-M12X100-12.9-UNPLTD | CH660/CS660/S6800/H6800 | |
| 841.0028-00 | SCREW | CH660/CS660 | |
| 842.0013.00 | SCREW, SET, HEXAGON SOCKET, CUP POINT ISO4029-M12X50-45H-A3R | CH660/CS660/S6800/H6800 | |
| 842.0013-00 | SCREW | CH660/CS660 | |
| 843.1267-00 | STUD SCREW 12X45 5,8 S&H6000 | UH640/CH660/H6800 | |
| 843.1511-00 | STUD BOLT | UH640/CH660/H6800 | |
| 847.0059.00 | WASHER TBRSB 13,5X36 1370 | CH660/CS660/S6800/H6800 | |
| 847.0132-00 | WASHER | CH660/CS660 | |
| 847.0171-00 | WASHER | CS660 | |
| 853.0119-00 | PARALLEL PIN | UH640/CH660/H6800 | |
| 853.0983.00 | PIN 2172-00 D40X40 /S6800 | CH660/CS660/S6800/H6800 | |
| 853.0983-00 | PIN | S6800 | |
| 855.0132.00 | RETAING RING SGA 110 SS1581 | CH660/CS660/S6800/H6800 | |
| 857.0350.00 | KEY T 25X14X95 | CH660/CS660/S6800/H6800 | |
| 857.0350-00 | KEY T 25X14X95 SMS 2307 H6000 | UH640/CH660/H6800 | |
| 863.0058-00 | DISC SPRING 90X46X5 H4000 | UH640/CH660/H6800 | |
| 868.0799.00 | SPHERICAL ROLLER BEARING 22224 E/C3 | CH660/CS660/S6800/H6800 | |
| 868.0799-00 | SPHERICAL ROLLER BEARING H6000 | UH640/CH660/H6800 | |
| 868.0806.00 | SPHERIC BEARING  452324 M2/W502, 8 | CH660/CS660/S6800/H6800 | |
| 868.0806-00 | SPHER ROLLER BEARNG H6000 | UH640/CH660/H6800 | |
| 873.0128.00 | O-RING 109,1X5,7 SMS1586 | CH660/CS660/S6800/H6800 | |
| 873.0128-00 | O-RING | CH660/CS660 | |
| 873.1152.00 | O-RING 625 X7 SMS1587 | CH660/CS660/S6800/H6800 | |
| 873.1152-00 | O-RING 625 X7 SMS1587 H6000 | UH640/CH660/H6800 | |
| 873.1153.00 | O-RING 510 X5,7 SMS1587 (FOR OLDER COVER 442.8726-01) | CH660/CS660/S6800/H6800 | |
| 873.1153-00 | O-RING 510 X5,7 SMS1587 H6000 | UH640/CH660/H6800 | |
| 873.1160 | RING | CH660/CS660/S6800/H6800 | |
| 873.1160.00 | O-RING 529,3X5,7 SMS1587 H6000 - OLD STYLE | CH660/CS660/S6800/H6800 | |
| 873.1160-00 | O-RING 529,3X5,7 SMS1587 H6000 | UH640/CH660/H6800 | |
| 873.1161.00 | SEAL RING 150x180x15 ISO 6194-1 | CH660/CS660/S6800/H6800 | |
| 873.1161-00 | OIL SEAL RING CC H6000 OIL SEAL R | UH640/CH660/H6800 | |
| 873.1277.00 | O-RING 548,0X5,7 SMS 1586 CH/CS660 | CH660/CS660/S6800/H6800 | |
| 873.1277-00 | O-RING | CH/CS660 | |
| 873.1401.00 | O-RING 594,1X5,7 SMS1587 CH6600 - NEW STYLE | CH660/CS660/S6800/H6800 | |
| 873.1401-00 | O-RING | CH660/H6000 | |
| 891.1647.901 | INSPECTION DOOR PU | CH660/CS660/S6800/H6800 | |
| 891.1772.901 | RUBBER LINER ASSEMBLY BOTTOMSHELL, 5-ARM / CH/CS660 | CH660/CS660/S6800/H6800 | |
| 891.1772-901 | RUBBER LINER ASSEMBLY | CH/CS660 | |
| 891.2133.901 | RUBBER PLATE KIT | CH660/CS660/S6800/H6800 | |
| 899.0157.00 | BOLT, EYE, LIFTING M48 | CH660/CS660/S6800/H6800 | |
| 900.0243-00 | SCRENED SOCKET | UH640/CH660/H6800 | |
| 900.0431.00 | FITTING, COMPRESSION GE 15-LR | CH660/CS660/S6800/H6800 | |
| 900.0431-00 | FITTING, COMPRESSION | CH660 | |
| 900.0654.00 | ADAPTER G1/2 BxG 172B | CH660/CS660/S6800/H6800 | |
| 900.0921-00 | TEE CPLG 3/4 SA 4072,415 H6000 | UH640/CH660/H6800 | |
| 900.1262-00 | ADAPTER | CH/CS660 | |
| 900.1412-00 | PIPE 3/4 X 70 KREA SMS 1787 | UH640/CH660/H6800 | |
| 900.2026-00 | MAGNETIC PLUG 3/4 S&H6000 | UH640/CH660/H6800 | |
| 900.2108.00 | ELBOW R4 ISO49 A4" | CH660/CS660/S6800/H6800 | |
| 900.2108-00 | ELBOW 4?? A4 SMS 435 | UH640/CH660/H6800 | |
| 900.2624.00 | JAM NUT 1/2 INCH | CH660/CS660/S6800/H6800 | |
| 919.0170-00 | BLADDER COMPLETE 20L H3800/H6800 | UH640/CH660/H6800 | |
| 919.0174-00 | ACCUMULATOR ASM H6000 FOR BLADDE | UH640/CH660/H6800 | |
| 923.0521.00 | CURRENT TRANSDUCER | CH660/CS660/S6800/H6800 | |
| 966.3828.00 | SWITCH, PUSH BUTTON | CH660/CS660/S6800/H6800 | |
| 966.3828-00 | SWITCH, PUSH BUTTON | CH/CS660 | |
| 972.0532-00 | MOTOR MBT112M 1800RPM 6HP LUBE H6800 | UH640/CH660/H6800 | |
| 975.0296.00 | POWER SUPPLY | CH660/CS660/S6800/H6800 | |
| 975.0296-00 | POWER SUPPLY | CH/CS660 | |
| 984.0623.00 | TRANSDUCER PROBE | CH660/CS660/S6800/H6800 | |
| 984.0623-00 | TRANSDUCER PROBE H/S 6000 | UH640/CH660/H6800 | |
| BG00248051 | SPIDER BUSHING | CH660 S6800 H6800 CS660 | |
| BG00325390 | MAIN SHAFT SLEEVE TAPERED CH/CS660 / BLOCK U.S.A. | CH660/CS660/S6800/H6800 | |
| BG00395290 | TOPSHELL PACKAGE | CH660 | |
| BG00395488/452.4131.901 | TOP SHELL ASSY / RAISED ARMS CH660 (NEW STYLE) | CH660/CS660/S6800/H6800 | |
| BG00395488/452.4131-901 | TOP SHELL ASSY | CH660 | |
| BG00417468 | CONCAVE | CH660 H6800 | |
| BG00420396 | CONCAVE | CH660 H6800 | |
| BG00420397 | CONCAVE | CH660 H6800 | |
| BG00420434 | CONCAVE | CH660 H6800 | |
| BG00420435 | CONCAVE | CH660 H6800 | |
| BG00565178 | BOTTOM SHELL | CH/CS660 | |
| BG00565215 | BOTTOM SHELL | CH/CS660 |
Write your message here and send it to us
